SEALANTS-Temperature Ranges
| Sealants and Variations |
Temp. based on travel.(Minimum) |
Temp. based on travel.(Maximum) |
Degradation temp. of cured sealant |
| 1X/1X* |
200/93 |
350/176 |
1200/648 |
| 2X/2X* |
350/176 |
300/315 |
1200/648 |
| 2XH |
600/315 |
1000/537 |
1200/648 |
| 3 |
125/51 |
750/398 |
>750/398 |
| 4 |
300/149 |
1800/982 |
>1800/982 |
| 6/6XR*/6W |
-300/-184 |
300/148 |
350/176 |
| 10 |
500/260 |
1200/648 |
1500/815 |
| 11 |
150/65 |
600/315 |
1000/537 |
| 11 w/cat. |
40/4 |
150/65 |
1000/537 |
| 16X |
200/93 |
700/371 |
>700/371 |
| 18X/18XFG |
70/21 |
600/315 |
>600/315 |
| 19X |
400/204 |
850/426 |
>1200/648 |
| 77 |
-50/-46 |
500/260 |
>500/260 |
| 155K |
250/121 |
950/510 |
1200/648 |
| DB-22 |
-40/-40 |
350/176 |
>350/176 |
| DB-23 |
-40/-40 |
350/176 |
>350/176 |
| X36/X36* |
40/4 |
450/232 |
>450/232 |
| All temperatures, that are provided in celsius, have been rounded down to the whole number.This is typical to all tables for Sealants, Valve Packings and Liquids. |
VALVE PACKINGS-Temperature Ranges
| Valve Packings and Variations |
Temp. based on travel.(Minimum) |
Temp. based on travel.(Maximum) |
Degradation temp. of valve packing |
| VPAX/VPAX* |
0/-17 |
750/398 |
>750/398 |
| VPB/VPB-20VPBEC |
-100/-73 |
500/260 |
>500/260 |
| VPER |
0/-17 |
1400/760 |
>1400/760 |
| VPEPX |
0/-17 |
1400/760 |
>1400/760 |
| VPF |
-100/-73 |
500/260 |
>500/260 |
| VPGX |
0/-17 |
1200/648 |
>1200/648 |
| VPLX |
0/-17 |
600/315 |
>600/315 |
| VPOX |
-50/-45 |
500/260 |
>500/260 |
FIBERS-Temperature Ranges
| Fibers and Variations |
Temp. based on travel.(Minimum) |
Temp. based on travel.(Maximum) |
Degradation temp. of fiber |
| BULK X |
-50/-45 |
1200/648 |
1200/648 |
| F-10 |
-50/-45 |
500/260 |
500/260 |
| F-11F |
-50/-45 |
500/260 |
500/260 |
| F-14 |
-50/-45 |
500/260 |
500/260 |
| F-41 |
-50/-45 |
1200/648 |
1200/648 |
| F-46,F-46 CG |
-50/-45 |
1200/648 |
1200/648 |
| F-54 |
-50/-45 |
1200/648 |
1200/648 |
| G-FIBER |
-50/-45 |
750/398 |
750/398 |
| G-FIBER* |
|
|
|
| G-FIBER CG |
|
|
|
| G-FIBER FG |
|
|
|
| Fiber(s) can be added to sealant and liquids to increase bulk.
This may help in bridging leaking orifices or severe blows. |
LIQUIDS-Temperature Ranges
| Liquids |
Temp.(Minimum) |
Temp.(Maximum) |
Degradation temp. |
| 1 LIQ./1 LIQ.* |
200/93 |
500/260 |
1200/648 |
| 1 LIQ./CAT |
40/4 |
200/93 |
1200/648 |
| 1C LIQ. |
250/121 |
1200/648 |
>1200/648 |
| 2W LIQ./2W LIQ.* |
300/148 |
1200/648 |
>1200/648 |
| 16T LIQ. |
200/93 |
700/371 |
>700/371 |
| 19 LIQ. |
400/204 |
1200/648 |
>1200/648 |
| Liquids need to be mixed with fiber prior to injecting a repair. |
BONDERS-Temperature Ranges
| Bonders |
Temp.(Minimum) |
Temp.(Maximum) |
Degradation temp. |
| CB-42 |
-65/-53 |
150/65 |
350/176 |
| DB-22 |
-40/-40 |
350/176 |
>350/176 |
| DB-23 |
-40/-40 |
350/176 |
>350/176 |
| ES-1 |
40/4 |
350/176 |
>350/176 |
| TC-4 |
30/1 |
350/176 |
>350/176 |
| X-36/X-36* |
40/4 |
450/232 |
>450/232 |
| It is recommended to apply bonders at temperatures above 60 ℉/15 ℃ to allow the catalyst
to react with the resin. Bonders will withstand colder temperatures after they have cured. |
GASKET/THREAD SEALERS-Temperature Ranges
| Gasket/Thread Sealers |
Temp.(Minimum) |
Temp.(Maximum) |
Degradation temp. |
| PRI-101 |
150/65 |
750/398 |
>750/398 |
| PRI-102 |
150/65 |
1000/537 |
>1000/537 |
| PRI-201 |
40/4 |
450/232 |
>450/232 |
| PRI-250FP |
40/4 |
450/232 |
>450/232 |
